Unshielded unbalanced line coupling network, meeting IEC 61000-4-12 and GB/T 17626.12
◆ Decoupling peak value: maximum ±7.0kV
◆ Decoupling parameters: 4×20mH inductance (non-common mode rejection)
◆ Rated input voltage: 250Vac, 300Vdc
◆ Maximum current: 2A
◆ Maximum number of lines: 4
◆ Input/output port: banana socket
◆ Communication bandwidth: 100kHz/typical
◆ IEC 61000-4-12 Ed3.0
